Illuminated indicators of evacuation routes of the “Artlight” series

Index of evacuation routes of the “PS” type, designed to indicate evacuation exits in warning systems and managing the evacuation of people during a fire.

Example of an execution option:

1. Type of light indicators: PS1;
2. 12/24 – nominal supply voltage 12 V ±10% or 24 V ±10%; 220 – nominal supply voltage 230 V (±10%), 50 Hz;
3. 01 – no sound notification option; 02 – sound notification option available;
4. AK – with battery, 00 – without battery;
5. 01, 02, 03, … 22 – image code according to the table (00 – image according to the customer’s request)

The given example is deciphered as follows: Light indicator of the “Artlight” series for 230V with a battery arrow on a green background

Designation of PS versions

Image codes on pointers:

*Note: By default, the devices are set to 24 V voltage and increased brightness. If necessary, during mounting, the level of brightness and voltage can be changed using jumpers XS1/XS2 and XS3/XS4, see Fig. 1 in the device passport.
